| SYSTEM | |
| MB FORM FACTOR | Pico-ITX |
| CPU | Onboard Intel Atom® N150 Processor (Formerly Twin Lake, TDP 6W) |
| CHIPSET | Intel® SoC |
| MEMORY | 1 x DDR5 4800MT/s, Single Channel SO-DIMM, up to 32GB |
| BIOS | UEFI |
| WAKE ON LAN | Yes |
| WATCHDOG TIMER | 255 Levels |
| SECURITY | Intel® PTT (Integrated fTPM) |
| RTC BATTERY | Lithium Battery |
| DIMENSION (W X D) | 100.0 (W) x 72.0 (D) mm (3.9″ x 2.8″) |
| OS SUPPORT | Windows® 11 (64bit), Linux |
| POWER | |
| POWER REQUIREMENT | DC-in 12V |
| POWER ON MODE | AT / ATX (Default) Mode |
| CONNECTOR | DC Jack Internal 2-pin Header |
| DISPLAY | |
| GPU | Intel® Graphics |
| LVDS | 1 x 24-bit Dual Channel LVDS (Max. Resolution: 1920 x 1200 @60Hz, co-layout eDP) |
| HDMI® | 1 x HDMI® 1.4b (Max Resolution: 3840 x 2160@30Hz) |
| MULTIPLE DISPLAY | Support 2 Displays |
| AUDIO | |
| CODEC | Realtek Audio Codec |
| COMBO | 1 x Internal Header |
| LAN | |
| ETHERNET | 2 x RJ45 for Realtek® RTL8111H GbE |
| USB PORT | |
| USB | 2 x USB 3.2 Gen 2x1 (10Gbps, Formerly USB 3.1 Gen 2) Internal Header for 4 x USB 2.0 |
| SERIAL PORT | |
| COM | Internal Header for 2 x RS-232/422/485 |
| INTERNAL I/O | |
| GPIO | 8-Bit |
| SMBUS | Yes |
| FRONT PANEL | HDD Active LED, Power LED, Power On/Off, Reset |
| ADDITIONAL | 1 x AT/ATX Mode Selection |
| EXPANSION | |
| M.2 | 1 x M-Key 2280 (PCIe Gen 3 x2/SATA interface) support NVMe 1 x E-Key 2230 (USB 2.0/PCIe x1) for WIFI/BT Module |
| ENVIRONMENT & CERTIFICATION | |
| OPERATING TEMPERATURE | -20°C ~ 60°C (-4°F ~ 140°F) |
| STORAGE TEMPERATURE | -20°C ~ 85°C (-4°F ~ 185°F) |
| OPERATING HUMIDITY | 10 ~ 90% relative humidity, non-condensing |
| CERTIFICATION | CE/FCC Class A |
TOP∧
| PART NUMBER | DESCRIPTION | QTY |
| Part Number | Description | QTY per Board |
| PIC-TWL1 | PIC-TWL1 MB | 1 |
| G01-COM-H2M22-1F | COM Cable | 1 |
| F05-PICO-01-F | Heatsink | 1 |
| PART NUMBER | PIC-TWL1-N1500010 |
| CPU | Intel® Atom® N150 Processor |
