| SYSTEM | |
| CPU | Intel® LGA1151 8th Gen Socket Processor (Formerly Coffee Lake-S, TDP 35W) |
| CHIPSET | Intel® H310 |
| MEMORY | 2 x DDR4 3200MHz, Dual Channel SO-DIMM, up to 32GB |
| BIOS | SPI 128MB Flash ROM |
| WATCHDOG TIMER | 255 Levels |
| OS SUPPORT | Windows® 11 (64bit) Windows® 10 (64bit) Linux |
| POWER | |
| POWER REQUIREMENT | DC-in 12~24V 60W Adapter: AC100~240V, DC12V/5.0A |
| POWER CONSUMPTION | 61.5W |
| DISPLAY | |
| HDMI | 1 x HDMI |
| VGA | 1 x VGA |
| AUDIO | |
| AMPLIFIER | 2 x 2W |
| LAN | |
| ETHERNET | 1 x RJ45 for Intel® i211-AT GbE 1 x RJ45 for Intel® I219-LM GbE |
| SYSTEM I/O | |
| I/O | 4 x USB 3.0 2 x USB 2.0 4 x RS-232 1 x HDMI 1 x VGA 1 x 8bit GPIO 1 x Line-out 1 x MIC-in 1 x Locking Jack 12~24V DC input 1 x Power Button |
| STORAGE | |
| SATA | 1 x 2.5” SATA bay |
| EXPANSION | |
| M.2 | 1 x M-Key 2242 1 x E-Key 2230 Support CNVi |
| MECHANICAL | |
| MOUNTING | Wall mount, Panel Mount, VESA Mount |
| DIMENSIONS (W x H x D) | 579.04 (W) x 360.46 (D) x 87.00 (H) mm |
| CONSTRUCTION | Aluminum Front Bezel + Metal Chassis |
| LCD | |
| DISPLAY TYPE | 23.8" TFT-LCD, LED |
| MAX. RESOLUTION | 1920 x 1080 |
| MAX. COLORS | 16.7M |
| LUMINACE | 250 nits |
| VIEWING ANGLE | 160° (H), 160° (V) |
| BACK LIGHT | LED |
| TOUCH SCREEN | |
| TYPE | Projected Capacitive Type |
| LIGHT TRANSMISSION | 85% |
| ENVIRONMENT & CERTIFICATION | |
| SHOCK | 15G, 1ms duration |
| VIBRATION | 1 Grms/ 5~ 500Hz/ Operation |
| OPERATING TEMPERATURE | -10°C ~ 50°C (14°F ~ 123°F) |
| STORAGE TEMPERATURE | -20°C ~ 70°C (-4°F ~ 158°F) |
| CERTIFICATION | CE/FCC Class A |
TOP∧
| PART NUMBER | DESCRIPTION | QTY |
| HPC238SC-FPH310 | HPC238SC-FPH310 | 1 |
| L01AS056-F | Adapter 19V/6.32A 120W | 1 |
| Change according to shipping area | Power Cord | 1 |
| J05-ANT-GX55240-F | L-Antenna | 1 |
| PART NUMBER | DESCRIPTION | QTY |
| HPC-HBD | Mounting Clips | 10 |
| PART NUMBER | HPC238SC-FPH310 |
| CPU | Intel® Socket LGA1151 CPU |
| POWER REQUIREMENT | DC-in 12~24V |
| HDMI | 1 x HDMI |
| VGA | 1 x VGA |
| ETHERNET | 2 x GbE |
| I/O | 4 x USB 3.0 |
| I/O | 2 x USB 2.0 |
| I/O | 4 x RS-232 |
| I/O | 1 x HDMI |
| I/O | 1 x VGA |
| I/O | 2 x RJ45 |
| I/O | 1 x GPIO |
| I/O | 1 x Line-out |
| I/O | 1 x MIC-in |
| I/O | DC-in Lockable |
| I/O | 1 x Power Button |
| SATA | 1 x 2.5” SATA Bay |
| M.2 | 1 x M-Key 2242 |
| M.2 | 1 x E-Key 2230 |
| OPERATING TEMPERATURE | -10°C ~ 50°C (14°F ~122°F) |
